Rotary Vibrating Screen
ROTARY VIBRATING SCREEN
Widely used in food, medicine, chemical industry, mining, metallurgy, construction material, coal and refractory material industries,etc.
Specifications
1.Function: screening and filtering any powder or particle material
2.Diameter: 600mm to 1800mm
3.Sieve layer: 1-5 layers, the 1-3 layers is better
4.Screen size range: 10mm-500 mesh.
5.Driven mode: vibration motor driven.
6.Material: carbon steel, material contact parts stainless steel or all stainless steel.
Model | Power(kw) | Diameter(mm) | Volume(mm) | Layers |
JET-600-1S | 800*800*680 | 1 | ||
JET-600-2S | 0.55kw | 600mm | 800*800*780 | 2 |
JET-600-3S | 800*800*880 | 3 | ||
JET-800-1S | 900*900*780 | 1 | ||
JET-800-2S | 0.75 kw | 800mm | 900*900*930 | 2 |
JET-800-3S | 900*900*1080 | 3 | ||
JET-1000-1S | 1160*1160*880 | 1 | ||
JET-1000-2S | 1.5 kw | 1000mm | 1160*1160*1030 | 2 |
JET-1000-3S | 1160*1160*1180 | 3 | ||
JET-1200-1S | 1360*1360*980 | 1 | ||
JET-1200-2S | 1.75 kw | 1200 mm | 1360*1360*1160 | 2 |
JET-1200-3S | 1360*1360*1360 | 3 | ||
JET-1500-1S | 1850*1850*1130 | 1 | ||
JET-1500-2S | 2.2 kw | 1500mm | 1850*1850*1330 | 2 |
JET-1500-3S | 1850*1850*1550 | 3 | ||
JET-1800-1S | 2200*2200*1360 | 1 | ||
JET-1800-2S | 2.2 kw | 1800mm | 2200*2200*1460 | 2 |
JET-1800-3S | 2200*2200*1680 | 3 |
