Automatic Rotary Type Blister Cupboard Packing Machine

Machine application

This machine is suitable for the blister card packing of battery, stationery, food, medical equipment, toys, hard ward, electronics, auto parts, daily use product, cosmetic etc, such as the injector, solid gum, toy car, scissor, flashlight, battery, spark Plug, lip stick, hook, shaver, pencil etc.

Main features

A.Mechanical transmission, servo motor driving, encoder control, reasonable Structure, easy operation.

B. Rotating table type heat sealing which will improve the sealing result, reduce the mould expense and help to change the mould conveniently.

C. 304 stainless steel frame, beautiful appearance, convenient for cleaning.

D. PLC control system, frequency speed adjust, which will help to reduce the noise And improve the running stability of the machine.

E. Photoelectrical control, auto detection.

F. Separated card feeder, which will reduce the labor force.

G. The whole machine is separately designed, it is convenient to delivery with lift.

H. To design the mould and auto feeding method according to the product shape.

Main technical parameters

Maximum size of card 300 150mm( can be customized according to the demand of customer)
Maximum size of PVC 300 150mm( can be customized according to the demand of customer)
Cutting frequency 15-35 times/ minute
Travel range 40-150mm
Air pressure 0.5-0.8Mpa
Air flow ≥0.5m3/min
Total power 380V  50Hz  10.5kW
Main motor power 1.5kW
Overall dimension 2960 2040 1900mm(L W H)
Machine weight 1500kg
