Horizontal Cartoning Machine for blister (JET-C100)

Horizontal Cartoning Machine for blister (JET-100)

Functions and Options

  • The cartoning machine includes an automatic station to form the cartons. The carton boxes are held by vacuum
  • No suction carton by missing blister
  • No suction carton by missing leaflet
  • Automatically displaying device for trouble, speed and finished products counting
  • Machine stop running if no products or incorrect position of products. And stop automatically if incorrect position of product into carton after return or no cartons or out of leaflets continuous.
  • Adopt human-machine operation system.
  • International famous brand of electric components such for PLC touch screen, frequency inverters, etc
  • Stable performance, operation is easy Controls Sensors
  • Blister presence detection sensor
  • Leaflet presence detection sensor
  • Carton present detection sensor
Type JET-100
Dimensions in mm 3100×1100×1550(L×W×H)
Weight in kg 1400
